创建 package

在 Dart 生态系统中使用 packages 实现共享软件,比如一些 Library 和工具。本章将通过最常见的 Library Package 来介绍如何创建一个 Package。

The Dart ecosystem uses packages to share software such as libraries and tools. This page tells you how to create a package, with a focus on the most common kind of package, library packages.

Library Package 的组成

What makes a library package

下图展示了最简单的 Library Package 布局:

The following diagram shows the layout of the simplest library package:

root directory contains pubspec.yaml and lib/file.dart

Library 的最基本要求包括:

The minimal requirements for a library are:

pubspec 文件
Library 的 pubspec.yaml 文件与应用程序的 pubspec.yaml 文件相同— pubspec.yaml 文件中并没有特别的指出这个 Package 是一个 Library 。

pubspec file
The pubspec.yaml file for a library is the same as for an application package—there is no special designation to indicate that the package is a library.

lib 目录
如你所料, Library 的代码位于 lib 目录下,且对于其他 Package 是公开的。你可以根据需要在 lib 下任意创建组织文件结构。按照惯例,实现代码会放在 lib/src 目录下。 lib/src 目录下的代码被认为是私有的。其他 Package 应该永远不需要导入 src/... 目录下代码。通过导出 lib/src 目录的文件到一个 lib 目录的文件,实现对 lib/src 目录中 API 的公开。

lib directory
As you might expect, the library code lives under the lib directory and is public to other packages. You can create any hierarchy under lib, as needed. By convention, implementation code is placed under lib/src. Code under lib/src is considered private; other packages should never need to import src/.... To make APIs under lib/src public, you can export lib/src files from a file that’s directly under lib.


组织 Library Package

Organizing a library package

在创建一个小的,独立的 Library(称之为 Mini Library)。 Library Package 非常容易维护,扩展和测试。大多数情况下,除非存在两个类紧密耦合的情况,否则每个类都应该将自己视为一个 Mini Library 。

Library packages are easiest to maintain, extend, and test when you create small, individual libraries, referred to as mini libraries. In most cases, each class should be in its own mini library, unless you have a situation where two classes are tightly coupled.

直接在 lib 目录下创建“主” Library 文件,lib/<package-name>.dart,该文件导出所有的公开的 API 。这样就可以允许使用者导入单个文件就能够获得 Library 的所有功能。

Create a “main” library file directly under lib, lib/<package-name>.dart, that exports all of the public APIs. This allows the user to get all of a library’s functionality by importing a single file.

lib 目录还可能包含其他可导入的非src Library。例如,主 Library 可能是跨平台的,但创建的独立 Library 依赖于 dart:io 或 dart:html 。 Some packages have separate libraries that are meant to be imported with a prefix, when the main library is not.(无法确切理解含义,暂未翻译)

The lib directory might also include other importable, non-src, libraries. For example, perhaps your main library works across platforms, but you create separate libraries that rely on dart:io or dart:html. Some packages have separate libraries that are meant to be imported with a prefix, when the main library is not.

这里让我们来看下一个真实 Library Package 的组织结构:shelf 。 shelf Package 提供了一种使用 Dart 创建 Web 服务器的简便方法,它的布局在 Dart Library Package 中是一种常用布局:

Let’s look at the organization of a real-world library package: shelf. The shelf package provides an easy way to create web servers using Dart, and is laid out in a structure that is commonly used for Dart library packages:

shelf root directory contains example, lib, test, and tool subdirectories

主 Library 文件 shelf.dart 在 lib 目录下,通过 shelf.dart 文件导出 lib/src 目录下的若干文件。为了不导出过多的 API,并且为开发者提供公开的 API 的概览, shelf.dart 使用了 show 来指定哪些内容需要导出:

Directly under lib, the main library file, shelf.dart, exports API from several files in lib/src. To avoid exposing more API than intended—and to give developers an overview of the entire public API of the package—shelf.dart uses show to specify exactly which symbols to export:

export 'src/cascade.dart' show Cascade;
export 'src/handler.dart' show Handler;
export 'src/hijack_exception.dart' show HijackException;
export 'src/middleware.dart' show Middleware, createMiddleware;
export 'src/middleware/add_chunked_encoding.dart' show addChunkedEncoding;
export 'src/middleware/logger.dart' show logRequests;
export 'src/middleware_extensions.dart' show MiddlewareExtensions;
export 'src/pipeline.dart' show Pipeline;
export 'src/request.dart' show Request;
export 'src/response.dart' show Response;
export 'src/server.dart' show Server;
export 'src/server_handler.dart' show ServerHandler;

在 shelf Package 中同样包含了 Mini Library:shelf_io 。适配器用来处理来自 dart:io 的 HttpRequest 对象。

The shelf package also contains a mini library: shelf_io. This adapter handles HttpRequest objects from dart:io.

导入 Library 文件

Importing library files

在从其他 package 导入 Library 文件时,使用 package: 命令来指定文件的 URI 。

When importing a library file from another package, use the the package: directive to specify the URI of that file.

import 'package:utilities/utilities.dart';

在两个文件都在 lib 目录中,或两个文件都在 lib 目录外,我们都可以使用相对路径的方式导入 Library 。但是,如果两个文件不都在 lib 目录中,需要对 lib 内或者 lib 外进行查找,那么此时必须要使用 package: 导入。如果对当前使用存在疑惑,那么直接 package:package: 满足所有情况。

When importing a library file from your own package, use a relative path when both files are inside of lib, or when both files are outside of lib. Use package: when the imported file is in lib and the importer is outside.

下面图片展示分别从 lib 和 web 目录中导入 lib/foo/a.dart

The following graphic shows how to import lib/foo/a.dart from both lib and web.

lib/bar/b.dart uses a relative import; web/main.dart uses a package import

条件导入或条件导出 Library 文件

Conditionally importing and exporting library files

如果你的 library 支持多平台,那么你应该会用到条件导入或条件导出 library 文件。常见的用例是,一个库同时支持 Web 和 Native 平台。

If your library supports multiple platforms, then you might need to conditionally import or export library files. A common use case is a library that supports both web and native platforms.

为了使用条件导入或条件导出,你需要检查是否存在 dart:* 库。下面是一个条件导出代码的样例,它将检查是否存在 dart:io and dart:html 库:

To conditionally import or export, you need to check for the presence of dart:* libraries. Here’s an example of conditional export code that checks for the presence of dart:io and dart:html:

export 'src/hw_none.dart' // Stub implementation
    if (dart.library.io) 'src/hw_io.dart' // dart:io implementation
    if (dart.library.html) 'src/hw_html.dart'; // dart:html implementation


Here’s what that code does:

  • 在一个可以使用 dart:io 的 app 中(例如一个命令行应用),导出 src/hw_io.dart

    In an app that can use dart:io (for example, a command-line app), export src/hw_io.dart.

  • 在一个 web 应用中可以使用 dart:html 导出 src/hw_html.dart

    In an app that can use dart:html (a web app), export src/hw_html.dart.

  • 若是其他情况,则导出 src/hw_none.dart

    Otherwise, export src/hw_none.dart.

要条件导入一个文件可以使用和上面一样的方式,仅需将 export 改为 import 即可。

To conditionally import a file, use the same code as above, but change export to import.

所有条件导出的库必须实现相同的 API。下面是 dart:io 实现的一个例子:

All of the conditionally exported libraries must implement the same API. For example, here’s the dart:io implementation:

import 'dart:io';

void alarm([String? text]) {
  stderr.writeln(text ?? message);

String get message => 'Hello World from the VM!';

这是一个默认实现,它会导致抛出 UnsupportedErrors

And here’s the default implementation, which uses stubs that throw UnsupportedError:

void alarm([String? text]) => throw UnsupportedError('hw_none alarm');

String get message => throw UnsupportedError('hw_none message');


On any platform, you can import the library that has the conditional export code:

import 'package:hw_mp/hw_mp.dart';

void main() {


Providing additional files

一个精心设计的 Library Package 很容易被测试。我们建议使用 test Package 编写测试用例,并将测试代码放到 Package 根目录的 test 目录中。

A well-designed library package is easy to test. We recommend that you write tests using the test package, placing the test code in the test directory at the top of the package.

如果要创建一个公用的命令行工具,应该将这些工具放到公共目录 bin 中。使用 pub global activate 命令行来运行工具。在 pubspec 的 executables 部分 列出的工具允许用户直接运行它而无需调用 pub global run

If you create any command-line tools intended for public consumption, place those in the bin directory, which is public. Enable running a tool from the command line, using dart pub global activate. Listing the tool in the executables section of the pubspec allows a user to run it directly without calling dart pub global run.

在 Library 中包含一个 example 程序演示如何使用 Library 是非常有用的。 example 程序在 Package 根目录的 example 目录中。

It’s helpful if you include an example of how to use your library. This goes into the example directory at the top of the package.

在开发过程中任何非公开的工具或可执行程序,应该放到 tool 文件夹。

Any tools or executables that you create during development that aren’t for public use go into the tool directory.

如果要将 Library 发布到 Pub 网站还要求一些其他的文件来描述 发布的 Package ,例如:README.mdCHANGELOG.md 文件。更多关于如何组织 Package 目录的内容,参见 Pub Package 布局约定

Other files that are required if you publish your library to the pub.dev site, such as README.md and CHANGELOG.md, are described in Publishing a package. For more information on how to organize a package directory, see the pub package layout conventions.

为 Library 制作文档

Documenting a library

使用 [dartdoc][] 可以为 Library 生成 API 文档。 dartdoc 解析源文件去查找使用 /// 语法标注的 文档注释

You can generate API docs for your library using the dart doc tool. dart doc parses the source looking for documentation comments, which use the /// syntax:

/// The event handler responsible for updating the badge in the UI.
void updateBadge() {

文档生成示例,参见 shelf 文档

For an example of generated docs, see the shelf documentation.

分发开源 Library

Distributing an open source library

如果 Library 是开源的,我们建议将他共享到 Pub 网站。使用 pub publish 来发布或者更新 Library,该命令将会上传 Package 并创建或更新其页面。示例参见 shelf Package 页面。有关如何准备发布 Package 的详细内容,参见 发布 Package

If your library is open source, we recommend sharing it on the pub.dev site. To publish or update the library, use pub publish, which uploads your package and creates or updates its page. For example, see the page for the shelf package. See Publishing a package for details on how to prepare your package for publishing.

Pub.dev 网站不仅仅是 Dart Packages 的发布网站, Pub 网站不仅用于托管 Package ,还能够生成托管 Package 的 API 参考文档。最新生成的文档的链接位于 Package 的 About 选项卡中; 示例参见 shelf Package 的 API 文档。链接到以前版本的文档,位于 Package 页面的 Versions 选项卡中。

The pub.dev site not only hosts your package, but also generates and hosts your package’s API reference docs. A link to the latest generated docs is in the package’s About box; for example, see the shelf package’s API docs. Links to previous versions’ docs are in the Versions tab of the package’s page.

为了确保 Package 的 API 文档在 Pub 网站上看起来更美观,请遵循以下步骤:

To ensure that your package’s API docs look good on the pub.dev site, follow these steps:

  • 在发布 Package 前,请通过执行 dart doc 工具确保文档能够生成成功且符合预期。

    Before publishing your package, run the dart doc tool to make sure that your docs generate successfully and look as expected.

  • 在发布 Package 后,请检查 Versions 选项卡,确保文档生成成功。

    After publishing your package, check the Versions tab to make sure that the docs generated successfully.

  • 如果文档没有生成,点击 Versions 选项卡中的 failed 查看 dartdoc 的输出。

    If the docs didn’t generate at all, click failed in the Versions tab to see the dart doc output.



通过运用以下资源来了解学习更多关于 Library Package 的内容:

Use the following resources to learn more about library packages:
